40" Radius CREE Double Row LED Light Bar

  • Sale
  • Regular price


Input Voltage: 9-32V DC
Power Consumption: 240W (3W*80pcs CREE XLAMP XBD LEDs)
Lumen Flux: 24720 lumen
Color Temperature: 6000K
Beam Pattern: Flood(90degree )/Spot(9degree) /Combo
Beam Angle: 90°/9°
Housing Material: 6061 Aluminum Extrusion
Housing Color: Black
Lens Material: PC Epoxy Coated Shatterproof Polycarbonate
Electronics: Integrated-Epoxy Encapsulated
Operating Temperature: -40C to +60C
IP Rating: IP68 Waterproof, Dust proof, Shockproof
Protections: Reverse Polarity
Current Draw: 17A @ 12V / 9A @ 24V
Dimensions: H 3”W 41 3/8” or 42 1⁄4” D 3.5”
